TPLINK AP AX1800 CEILING MOUNT EAP613

AX1800 Ceiling Mount Dual-Band Wi-Fi 6 Access Point PORT:1× Gigabit RJ45 Port SPEED:574Mbps at 2.4 GHz + 1201 Mbps at 5 GHz FEATURE: 802.3at POE and 12V DC (Power Adapter is not included), 2 ×Internal Antennas, MU-MIMO, Seamless Roaming, Band Steering, Beamforming, Load Balance, Airtime Fairness, Centralized Management by Omada SDN Controller, Omada App
Garantie: 60 luni


Specificatii tehnice

Antennas quantity: 4
Antenna type: Internal
Antenna gain level (max): 5 dBi
Certification: CE, FCC, RoHS
Placement: Ceiling, Wall
LED indicators: Yes
Product colour: White
Reset button: Yes
VLAN support: Yes
BeamForming: Yes
Networking standards: IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
MIMO: Yes
MIMO type: Multi User MIMO
Ethernet LAN data rates: 100,1000 Mbit/s
5 GHz: Yes
6 GHz: No
Maximum data transfer rate: 1775 Mbit/s
Maximum data transfer rate (2.4 GHz): 574 Mbit/s
Maximum data transfer rate (5 GHz): 1201 Mbit/s
Automatic channel selection: Yes
Automatic channel scanning: Yes
Spread spectrum method: OFDMA
Wi-Fi Multimedia (WMM)/(WME): Yes
Rate limiting: Yes
Wireless isolation: Yes
Band steering: Yes
Airtime Fairness (ATF): Yes
Transmitting power (CE): <20 dBm(2.4 GHz, EIRP); <23 dBm(5 GHz band1/2, EIRP); <25 dBm (5 GHz band3)
Transmitting power (FCC): <25 dBm (2.4 GHz) <25 dBm (5 GHz)
2.4 GHz: Yes
Frequency band: 2.4 - 5 GHz
Management platform: Omada
Web-based management: Yes
Storage relative humidity (H-H): 5 - 90%
Storage temperature (T-T): -40 - 70 °C
Operating temperature (T-T): 10 - 90 °C
Operating relative humidity (H-H): 0 - 40%
Quantity per pack: 1 pc(s)
Quick start guide: Yes
Mounting kit: Yes
Compatible operating systems: Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
DC-in jack: Yes
Ethernet LAN (RJ-45) ports: 1
USB 2.0 ports quantity: 0
Input current: 1 A
Power over Ethernet (PoE): Yes
Power over Ethernet (PoE) type supported: Passive PoE
DC voltage range: 12 V
Power consumption (typical): 9.6 W
Power consumption (max): 106 W
Security algorithms: HTTPS, SNMP, SNMPv2, SNMPv3, WPA, WPA2, WPA3
Number of SSID supported: 16
Depth: 160 mm
Height: 33.6 mm
Width: 160 mm
WiFi-Standard: ax
