TPL SW 8P-GB UNMNGD DESK METAL

Forwarding rate: 11.9 Mpps

LED indicators: Yes

Certification: CE, FCC, RoHS

Switching capacity: 16 Gbit/s

Supported data transfer rates: 10/100/1000Mbps

Maximum data transfer rate: 2 Gbit/s

Packet buffer memory: 1.5 MB

MAC address table: 4096 entries

Store-and-forward: Yes

Jumbo frames support: Yes

Jumbo frames: 16000

Rack mounting: No

Wall mountable: Yes

Product colour: Black

Ethernet LAN data rates: 10,100,1000 Mbit/s

Ethernet LAN: Yes

Quality of Service (QoS) support: Yes

Flow control support: Yes

Bandwidth: 16 Gbit/s

Networking standards: IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u, IEEE 802.3x

Harmonized System (HS) code: 85176990

Switch type: Unmanaged

Switch layer: L2

Multicast support: Yes

10G support: No

Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T

Auto-negotiation: Yes

Cable types supported: Cat3, Cat4, Cat5, Cat5e

MAC address auto-aging supported: Yes

MAC address auto-learning supported: Yes

Full duplex: Yes

Power over Ethernet (PoE): No

Auto MDI/MDI-X: Yes

Ethernet interface type: Gigabit Ethernet

Storage relative humidity (H-H): 5 - 90%

Storage temperature (T-T): -40 - 70 °C

Operating temperature (T-T): 0 - 40 °C

Operating relative humidity (H-H): 10 - 90%

Power LED: Yes

Packet transfer speed: 14880pps/148800pps/1488000pps

Wi-FI: No

Connectivity technology: Wired

Manual: Yes

Quick start guide: Yes

User guide: Yes

Cables included: AC

Package type: Box

Package height: 92 mm

Package width: 130 mm

Package weight: 510 g

Package depth: 191 mm

Installed QSFP+ modules quantity:

Gigabit Ethernet (copper) ports quantity: 8

Installed SFP+ modules quantity:

Basic switching RJ-45 Ethernet ports quantity: 8

Installed SFP modules quantity:

Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)

Power connector: DC-in jack

Power supply included: Yes

Input current: 0.6 A

Input voltage: 9 V

Power consumption (max): 33 W

Power source: DC

AC input voltage: 220 V

AC input frequency: 50 Hz

Switching protocols: CSMA/CD

GARP VLAN Registration Protocol (GVRP): Yes

IGMP snooping: Yes

Access Control List (ACL) IPv6 entries: 11

Depth: 101 mm

Height: 25 mm

Width: 158 mm

LAN port type: Gigabit

Garantia Produsului: 60 luni
