TPL SW 6P-GB POE-3P UNMNGD DESK

Certification: FCC, CE, RoHS

Forwarding rate: 8.928 Mpps

Switching capacity: 12 Gbit/s

Store-and-forward: Yes

MAC address table: 4000 entries

Stackable: Yes

Rack mounting: Yes

Ethernet LAN data rates: 10,100,1000 Mbit/s

Quality of Service (QoS) support: Yes

Flow control support: Yes

Networking standards: IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x

Switch type: Unmanaged

Power over Ethernet (PoE): Yes

Auto MDI/MDI-X: Yes

Cable types supported: Cat3, Cat4, Cat5, Cat5e, Cat6

10G support: No

MAC address auto-aging supported: Yes

Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T

Auto-negotiation: Yes

MAC address auto-learning supported: Yes

Heat dissipation: 16.2 BTU/h

Operating temperature (T-T): 0 - 40 °C

Operating relative humidity (H-H): 10 - 90%

Storage temperature (T-T): -40 - 70 °C

Storage relative humidity (H-H): 5 - 90%

Quick start guide: Yes

Package type: Box

Fanless: Yes

Power over Ethernet (PoE) ports quantity: 4

Installed SFP+ modules quantity:

Installed SFP modules quantity:

Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)

Basic switching RJ-45 Ethernet ports quantity: 6

DC input voltage: 53.5 V

Input current: 1.31 A

Power source: DC/PoE

Power consumption (typical): 4.75 W

Power consumption (max): 71.46 W

Power supply included: Yes

Total Power over Ethernet (PoE) budget: 64 W

IGMP snooping: Yes

Height: 25 mm

Depth: 101 mm

Width: 158 mm

LAN-Port-Type: Gigabit

Garantia Produsului: 60 luni
