TPL SW 16P-GB UNMNGD DESKTOP SWITCH POE

Jumbo frames support: Yes

MAC address table: 8000 entries

Jumbo frames: 9000

Switching capacity: 32 Gbit/s

Store-and-forward: Yes

Number of queues: 4

Packet buffer memory: 4.1 MB

Forwarding rate: 23.81 Mpps

Housing material: Metal

Wall mountable: Yes

Stackable: Yes

VLAN support: Yes

Quality of Service (QoS) support: Yes

Flow control support: Yes

Rate limiting: Yes

Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3ab, IEEE 802.3u

Switch type: Unmanaged

Port mirroring: Yes

Full duplex: Yes

Power over Ethernet (PoE): Yes

Link aggregation: Yes

Cable types supported: Cat3, Cat4, Cat5, Cat5e, Cat6

Broadcast storm control: Yes

Copper ethernet cabling technology: 10BASE-T, 100BASE-TX, 1000BASE-T

Auto-negotiation: Yes

Auto MDI/MDI-X: Yes

Number of VLANs: 32

Cable length detection: Yes

Virtual LAN features: Protocol-based VLAN, Tagged VLAN

Heat dissipation: 490.55 BTU/h

Operating temperature (T-T): 0 - 40 °C

Operating relative humidity (H-H): 10 - 90%

Storage temperature (T-T): -40 - 70 °C

Storage relative humidity (H-H): 5 - 90%

Quick start guide: Yes

Package height: 70 mm

Package depth: 434 mm

Package weight: 2 kg

Package width: 227 mm

Gigabit Ethernet (copper) ports quantity: 16

Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)

Basic switching RJ-45 Ethernet ports quantity: 16

Input current: 0.6 A

Power supply included: Yes

DC input voltage: 9 V

Power consumption (typical): 11.72 W

Power consumption (max): 144.28 W

AC input voltage: 220 V

AC input frequency: 50 Hz

IGMP snooping: Yes

Loop protection: Yes

Width: 286 mm

Depth: 111.7 mm

Height: 25.4 mm

LAN-Port-Type: Gigabit

Garantia Produsului: 60 luni
