TPL MC WDM GB TO FO SM SC 20KM TYPE B

"Omada 10/100 Mbps RJ45 to 100 Mbps Single-mode SC WDM Bi-Directional Fiber Converter PORT: 1× 100Mbps SC Port, 1× 10/100M RJ45 Port (Auto MDI/MDIX) SPEC: Full-duplex, Tx:1310 nm, Rx:1550 nm, Up to 20 km, Chassis TL-MC1400 rack-mountable"
Garantie: 60 luni


Specificatii tehnice

Compliance certificates: RoHS
Certification: FCC, CE
LED indicators: Yes
Product colour: Black
Internal: No
Harmonized System (HS) code: 85176990
Cable types supported: Cat3, Cat4, Cat5
Maximum data transfer rate: 100 Mbit/s
Fiber ethernet cabling technology: 100BASE-FX
Ethernet LAN data rates: 10,100 Mbit/s
Auto MDI/MDI-X: Yes
Networking standards: IEEE 802.3, IEEE 802.3u
Duplex system: Full, Half
Ethernet interface type: Gigabit Ethernet
Copper ethernet cabling technology: 10BASE-TX, 100BASE-FX, 100BASE-TX
Storage relative humidity (H-H): 5 - 90%
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 70 °C
Package width: 165 mm
Package height: 65 mm
Package depth: 204 mm
Package weight: 360 g
Wavelength: 1550 nm
Maximum transfer distance: 20000 m
Wavelength-division multiplexing (WDM): Yes
Fiber mode structure: Single-mode
Fiber optic connector: SC
Fiber ports quantity: 1
Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 1
Power consumption (max): 2.41 W
Width: 95 mm
Height: 27 mm
Depth: 73 mm
MC-Standard: FastEthernet
MC-Type: Single mode
