TPL MC WDM GB TO FO SM SC 20KM TYPE A

"Omada 10/100 Mbps RJ45 to 100 Mbps Single-mode SC WDM Bi-Directional Fiber Converter PORT: 1× 100Mbps SC Port, 1× 10/100M RJ45 Port (Auto MDI/MDIX) SPEC: Full-duplex, Tx:1550 nm, Rx:1310 nm, Up to 20 km, Chassis TL-MC1400 Rack-mountable"
Garantie: 60 luni


Specificatii tehnice

Compliance certificates: RoHS
LED indicators: Yes
Product colour: Black
Internal: No
Harmonized System (HS) code: 85176990
Maximum data transfer rate: 100 Mbit/s
Networking standards: IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates: 10,100 Mbit/s
Auto MDI/MDI-X: Yes
Cable types supported: Cat3, Cat4, Cat5, Cat5e
Duplex system: Full, Half
Storage relative humidity (H-H): 5 - 90%
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 10 - 90%
Storage temperature (T-T): -40 - 70 °C
Manual: Yes
Fiber ports quantity: 1
Maximum transfer distance: 20000 m
Wavelength-division multiplexing (WDM): Yes
Fiber mode structure: Single-mode
Fiber optic connector: SC
Connectivity technology: Wired
Ethernet LAN (RJ-45) ports: 1
Power consumption (max): 24.9 W
Height: 27 mm
Width: 95 mm
Depth: 73 mm
MC-Standard: FastEthernet
MC-Type: Single mode
