D-Link DGS-1100-24V2 Managed L2 Gigabit

D-Link DGS-1100-24V2. Switch type: Managed, Switch layer: L2. Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000), Basic switching RJ-45 Ethernet ports quantity: 24. Full duplex. MAC address table: 8000 entries, Switching capacity: 48 Gbit/s. Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3x. Rack mounting, Form factor: 1U
Garantie: 24 luni


Specificatii tehnice

Forwarding rate: 35.71 Mpps
LED indicators: Yes
Compliance certificates: BSMI, CB, CCC, cUL
Certification: FCC, CE, VCCI, C-Tick, BSMI, CCC
Packet buffer memory: 4.1 MB
Switching capacity: 48 Gbit/s
MAC address table: 8000 entries
Jumbo frames: 9216
Jumbo frames support: Yes
Rack mounting: Yes
Form factor: 1U
Product colour: Black, Grey
Ethernet LAN data rates: 10,100,1000 Mbit/s
VLAN support: Yes
Quality of Service (QoS) support: Yes
Flash memory: 16 MB
Rate limiting: Yes
Flow control support: Yes
Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3x
Mean time between failures (MTBF): 424762 h
Web-based management: Yes
Switch type: Managed
Switch layer: L2
Full duplex: Yes
Link aggregation: Yes
Auto MDI/MDI-X: Yes
Power over Ethernet (PoE): No
Port mirroring: Yes
Head-of-line (HOL) blocking: Yes
Virtual LAN features: Port-based VLAN
Number of VLANs: 128
Auto-negotiation: Yes
10G support: No
Half duplex: Yes
Broadcast storm control: Yes
Spanning tree protocol: Yes
Operating temperature (T-T): -5 - 50 °C
Heat dissipation: 54.3 BTU/h
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 0 - 95%
Storage relative humidity (H-H): 0 - 95%
Installed SFP modules quantity: 0
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Installed SFP+ modules quantity: 0
Basic switching RJ-45 Ethernet ports quantity: 24
Power source: AC
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Number of power supply units: 1
Power supply included: Yes
Power consumption (max): 15.9 W
IGMP snooping: Yes
Loop protection: Yes
Sustainability compliance: Yes
Depth: 180 mm
Height: 44 mm
Width: 280 mm
Weight: 1.32 kg
