D-Link DGS-1100-24V2 Managed L2 Gigabit

Compliance certificates: BSMI, CB, CCC, cUL

Certification: FCC, CE, VCCI, C-Tick, BSMI, CCC

Jumbo frames support: Yes

MAC address table: 8000 entries

Jumbo frames: 9216

Packet buffer memory: 4.1 MB

Forwarding rate: 35.71 Mpps

Switching capacity: 4.8 Gbit/s

Product colour: Black, Grey

LED indicators: Yes

Rack mounting: Yes

Form factor: 1U

Ethernet LAN data rates: 10,100,1000 Mbit/s

VLAN support: Yes

Quality of Service (QoS) support: Yes

Flash memory: 16 MB

Flow control support: Yes

Rate limiting: Yes

Networking standards: IEEE 802.1Q, IEEE 802.1p, IEEE 802.3ad, IEEE 802.3az, IEEE 802.3x

Mean time between failures (MTBF): 424762 h

Web-based management: Yes

Switch type: Managed

Switch layer: L2

Auto MDI/MDI-X: Yes

Power over Ethernet (PoE): No

Port mirroring: Yes

Auto-negotiation: Yes

Link aggregation: Yes

Full duplex: Yes

Number of VLANs: 128

Head-of-line (HOL) blocking: Yes

Virtual LAN features: Port-based VLAN

10G support: No

Half duplex: Yes

Broadcast storm control: Yes

Spanning tree protocol: Yes

Heat dissipation: 54.3 BTU/h

Storage temperature (T-T): -40 - 70 °C

Operating relative humidity (H-H): 0 - 95%

Operating temperature (T-T): 5 - 50 °C

Storage relative humidity (H-H): 0 - 95%

Basic switching RJ-45 Ethernet ports quantity: 24

Installed SFP+ modules quantity:

Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)

Number of power supply units: 1

Power supply included: Yes

Power consumption (max): 15.9 W

Power source: AC

AC input voltage: 100 - 240 V

AC input frequency: 50/60 Hz

IGMP snooping: Yes

Loop protection: Yes

Sustainability compliance: Yes

Width: 280 mm

Height: 44 mm

Depth: 180 mm

Weight: 1.32 kg

Garantia Produsului: 24 luni
