Omada 24-Port Gigabit Stackable Lite L3

Omada 24-Port Gigabit Stackable Lite L3 Managed Switch with 4 10G Slots PORT: 24× Gigabit RJ45 Ports, 4× 10G SFP+ Slots, RJ45/USB Type C Console Port, 1× USB2.0 Port SPEC: 1U 19-inch Rack-mountable Steel Case FEATURE: Centralized Managed by Omada SDN Controller, Stacking, RIP, OSPF, Static Routing, ERPS, OAM, sFlow, DDM, 802.1Q VLAN, QinQ, STP/RSTP/MSTP, IGMP Snooping, 802.1p/DSCP QoS, ACL, 802.1x, Radius/Tacacs+ Authentication, LACP, CLI, SNMP, Dual Image/Configuration, IPv6
Garantie: 24 luni


Specificatii tehnice

Stackable: Yes
Console port: RJ-45
Forwarding rate: 95.23 Mpps
LED indicators: Yes
Compliance certificates: CE, Federal Communications Commission (FCC), RoHS
Switching capacity: 128 Gbit/s
Store-and-forward: Yes
Packet buffer memory: 12 MB
Jumbo frames: 9000
MAC address table: 16000 entries
Jumbo frames support: Yes
Rack mounting: Yes
Built-in processor: Yes
Mean time between failures (MTBF): 519.543 h
Bandwidth: 64 Gbit/s
VLAN support: Yes
Quality of Service (QoS) support: Yes
Processor frequency: 1200 MHz
Flash memory: 512 MB
Surge protection: Yes
Networking standards: IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
ARP inspection: Yes
Switch layer: L3
Firmware upgradeable: Yes
Web-based management: Yes
Switch type: Managed
Cloud-managed: Yes
Multicast support: Yes
Broadcast storm control: Yes
Number of VLANs: 4000
Security algorithms: SNMP, SNMPv2, SNMPv3
10G support: Yes
Port mirroring: Yes
Link aggregation: Yes
Power over Ethernet (PoE): No
Virtual LAN features: MAC address-based VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN
Heat dissipation: 66.87 BTU/h
Operating temperature (T-T): -5 - 45 °C
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 10 - 90%
Storage relative humidity (H-H): 5 - 90%
Management level: 4
Cables included: AC
Rack mount kit: Yes
Processor manufacturer: ARM
Telnet: Yes
Memory type: DRAM
Physical stacking (units): 4
Fanless: Yes
SFP module slots quantity: 4
Installed SFP+ modules quantity: 0
Basic switching RJ-45 Ethernet ports quantity: 24
Gigabit Ethernet (copper) ports quantity: 24
USB 2.0 ports quantity: 1
USB Type-C ports quantity: 1
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Power supply included: Yes
Surge protection voltage: 6 kV
Power consumption (max): 19.6 W
Power source: AC
MAC address filtering: Yes
Access Control List (ACL): Yes
IGMP snooping: Yes
DHCP features: DHCP relay, DHCP server
Password protection: Yes
SSH/SSL support: Yes
Static port security: Yes
IP-MAC-Port binding: Yes
Width: 440 mm
Height: 44 mm
Depth: 180 mm
