Omada 10-Port Gigabit EasyManaged Switch

Compliance certificates: CE, Federal Communications Commission (FCC), RoHS

Jumbo frames support: Yes

MAC address table: 8000 entries

Packet buffer memory: 4 MB

Store-and-forward: Yes

Switching capacity: 12 Gbit/s

Forwarding rate: 7.4 Mpps

Jumbo frames: 15

Product colour: Black

LED indicators: Yes

Stackable: No

Reset button: Yes

Wall mountable: Yes

VLAN support: Yes

Surge protection: Yes

Flow control support: Yes

Quality of Service (QoS) support: Yes

Networking standards: IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3at, IEEE 802.3x

Unified static configuration: Yes

Web-based management: Yes

Switch type: Managed

Firmware upgradeable: Yes

Cloud-managed: Yes

Power over Ethernet (PoE): Yes

Link aggregation: Yes

Auto MDI/MDI-X: Yes

Port mirroring: Yes

Auto-negotiation: Yes

Zero Touch Provisioning (ZTP): Yes

Fast leave: Yes

10G support: No

Virtual LAN features: MTU VLAN, Port-based VLAN, Tagged VLAN

Operating relative humidity (H-H): 10 - 90%

Storage temperature (T-T): -40 - 70 °C

Storage relative humidity (H-H): 5 - 90%

Operating temperature (T-T): -5 - 40 °C

Transmission distance (max): 0.25 km

User guide: Yes

AC adapter included: Yes

Package type: Box

Fanless: Yes

Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)

Gigabit Ethernet (copper) ports quantity: 6

Power over Ethernet (PoE) ports quantity: 4

Basic switching RJ-45 Ethernet ports quantity: 6

DC input voltage: 53.5 V

Input current: 1.31 A

Surge protection voltage: 6 kV

Power supply included: Yes

Power source: DC

Power over Ethernet (PoE) type supported: PoE+

Power over Ethernet plus (PoE+) ports quantity: 4

Total Power over Ethernet (PoE) budget: 65 W

Power over Ethernet (PoE) power per port: 30 W

Loop protection: Yes

DHCP features: DHCP client

Queue scheduling algorithms: Weighted Round Robin (WRR)

IGMP snooping: Yes

Height: 25 mm

Depth: 101 mm

Width: 158 mm

Rackable: No

LAN-Port-Type: FastEthernet

LAN-Ports: 8

Redundant-PSU: No

Garantia Produsului: 36 luni
