DLINK SW 16P-GB EASY-SMART DESK/RM

Certification: EMI FCC A, CE A, VCCI A, C-Tick, BSMI, CCCncUL, CE LVD, CB, BSMI, CCC

Jumbo frames support: Yes

MAC address table: 8000 entries

Switching capacity: 32 Gbit/s

Jumbo frames: 9216

Number of queues: 4

Packet buffer memory: 4.1 MB

Forwarding rate: 23.81 Mpps

Store-and-forward: Yes

Product colour: Black

Rack mounting: Yes

LED indicators: Yes

Ethernet LAN data rates: 10,100,1000 Mbit/s

VLAN support: Yes

Quality of Service (QoS) support: Yes

Flash memory: 16 MB

Flow control support: Yes

Rate limiting: Yes

Built-in processor: Yes

Processor frequency: 125 MHz

Mean time between failures (MTBF): 710519 h

Harmonized System (HS) code: 85176990

Web-based management: Yes

System event log: Yes

Switch type: Managed

Switch layer: L2

Multicast support: Yes

10G support: No

Broadcast storm control: Yes

Spanning tree protocol: Yes

Copper ethernet cabling technology: 10BASE-T, 10BASE-TX, 1000BASE-T

Virtual LAN features: Port-based VLAN, Voice VLAN

Number of VLANs: 128

Head-of-line (HOL) blocking: Yes

Full duplex: Yes

Link aggregation: Yes

Auto MDI/MDI-X: Yes

Power over Ethernet (PoE): No

Port mirroring: Yes

Auto-negotiation: Yes

Operating altitude: 0 - 2000 m

Storage relative humidity (H-H): 0 - 95%

Heat dissipation: 34.46 BTU/h

Storage temperature (T-T): -40 - 70 °C

Operating relative humidity (H-H): 0 - 95%

Operating temperature (T-T): -5 - 50 °C

Noise level: 0 dB

Memory type: DRAM

Fanless: Yes

Installed SFP modules quantity:

Basic switching RJ-45 Ethernet ports quantity: 16

Installed SFP+ modules quantity:

Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)

Power source: AC

AC input voltage: 100 - 240 V

AC input frequency: 50/60 Hz

Power consumption (max): 10.1 W

IGMP snooping: Yes

DHCP features: DHCP client

Queue scheduling algorithms: SPQ, Weighted Round Robin (WRR)

Security algorithms: SNMP, SSL/TLS

Depth: 180 mm

Weight: 1.27 kg

Height: 44 mm

Width: 280 mm

LAN port type: Gigabit

Garantia Produsului: 60 luni
