DLINK SW 16P-GB EASY-SMART DESK/RM

D-Link Switch DGS-1100-16, 16 porturi Gigabit, Capacity 32Gbps, 8K MAC ,11" Desktop/Rackmount, Easy Smart, fanless, metal
Garantie: 60 luni


Specificatii tehnice

Forwarding rate: 23.81 Mpps
LED indicators: Yes
Certification: EMI FCC A, CE A, VCCI A, C-Tick, BSMI, CCCncUL, CE LVD, CB, BSMI, CCC
Number of queues: 4
Packet buffer memory: 4.1 MB
MAC address table: 8000 entries
Switching capacity: 32 Gbit/s
Jumbo frames: 9216
Store-and-forward: Yes
Jumbo frames support: Yes
Rack mounting: Yes
Product colour: Black
Ethernet LAN data rates: 10,100,1000 Mbit/s
VLAN support: Yes
Quality of Service (QoS) support: Yes
Flash memory: 16 MB
Flow control support: Yes
Rate limiting: Yes
Built-in processor: Yes
Mean time between failures (MTBF): 710519 h
Processor frequency: 125 MHz
Noise level: 0 dB
Harmonized System (HS) code: 85176990
Web-based management: Yes
System event log: Yes
Switch type: Managed
Switch layer: L2
Multicast support: Yes
10G support: No
Broadcast storm control: Yes
Spanning tree protocol: Yes
Head-of-line (HOL) blocking: Yes
Security algorithms: SNMP, SSL/TLS
Copper ethernet cabling technology: 10BASE-T, 10BASE-TX, 1000BASE-T
Virtual LAN features: Port-based VLAN, Voice VLAN
Number of VLANs: 128
Link aggregation: Yes
Full duplex: Yes
Auto MDI/MDI-X: Yes
Power over Ethernet (PoE): No
Port mirroring: Yes
Auto-negotiation: Yes
Operating altitude: 0 - 2000 m
Storage relative humidity (H-H): 0 - 95%
Heat dissipation: 34.46 BTU/h
Storage temperature (T-T): -40 - 70 °C
Operating relative humidity (H-H): 0 - 95%
Operating temperature (T-T): -5 - 50 °C
Memory type: DRAM
Fanless: Yes
Installed SFP+ modules quantity: 0
Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity: 16
Installed SFP modules quantity: 0
Power source: AC
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Power consumption (max): 10.1 W
IGMP snooping: Yes
DHCP features: DHCP client
Queue scheduling algorithms: SPQ, Weighted Round Robin (WRR)
Depth: 180 mm
Weight: 1.27 kg
Height: 44 mm
Width: 280 mm
LAN port type: Gigabit
