MB Gigabyte B550M X A ELITE

Placa de baza Gigabyte B550M X A ELITE


Specificatii tehnice

Lithium weight per battery: 0.07 g
Battery capacity: 220 mAh
Battery weight: 3 g
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
BIOS type: UEFI AMI
PCI Express x4 slots: 1
1st M.2 largest key size: 2280
2nd M.2 largest key size: 2280
2nd M.2 highest PCI Express generation: 3.0
1st M.2 highest PCI Express generation: 4.0
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 2
Cooling type: Passive
Motherboard chipset: AMD B550
Audio output channels: 7.1 channels
Component for: PC
Product colour: Black
Audio Chip: Realtek ALC1220-VB
Motherboard form factor: micro ATX
Motherboard chipset family: AMD
Power source type: ATX
Parallel processing technology support: Not supported
DirectX version: 12.0
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 0
Number of SATA III connectors: 4
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
CPU fan connector: Yes
Front panel connector: Yes
TPM connector: Yes
USB 2.0 connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
Maximum internal memory per slot: 32 GB
Supported memory types: DDR4-SDRAM
Supported memory clock speed (max): 3200 MHz
ECC сompatibility: ECC & Non-ECC
Number of memory slots: 4
Memory slots type: DIMM
Unbuffered memory: Yes
Memory channels: Dual-channel
Maximum internal memory: 128 GB
Wi-FI: No
Ethernet LAN: Yes
Ethernet interface type: 2.5 Gigabit Ethernet
LAN controller: Realtek RTL8125
Weight: 1.04 kg
Batteries included: Yes
Screws included: Yes
Package height: 68 mm
Package weight: 2.26 kg
Package width: 270 mm
Package depth: 268 mm
Compatible processor series: AMD Ryzen 5000 Series, AMD Ryzen 4000 Series, AMD Ryzen 3000 Series
Supported processor sockets: Socket AM4
Processor socket: Socket AM4
Processor manufacturer: AMD
USB 2.0 ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
Line-in: Yes
HDMI ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
DVI-D ports quantity: 0
DisplayPorts quantity: 1
VGA (D-Sub) ports quantity: 0
Ethernet LAN (RJ-45) ports: 1
Microphone in: Yes
Headphone outputs: 1
RAID levels: 0, 1, 10
Number of storage drives supported: 6
Number of HDDs supported: 4
RAID support: Yes
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, PCI Express 4.0, PCI Express 3.0, SATA III
Warranty period: 3 year(s)
Height: 35 mm
Width: 244 mm
Depth: 244 mm
