MB Gigabyte B550 X GAMING

Placa de baza Gigabyte B550 X GAMING


Specificatii tehnice

Lithium weight per battery: 0.07 g
Battery capacity: 220 mAh
Battery weight: 3 g
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
ACPI version: 5.0
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
BIOS memory size: 128 Mbit
BIOS type: UEFI AMI
Clear CMOS jumper: Yes
1st M.2 largest key size: 25110
2nd M.2 largest key size: 22110
PCI Express x1 (Gen 3.x) slots: 2
PCI Express x16 (Gen 3.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 2
1st M.2 highest PCI Express generation: 4.0
2nd M.2 highest PCI Express generation: 3.0
Product colour: Dark brown
Power source type: ATX
Cooling type: Passive
Motherboard chipset: AMD B550
Audio output channels: 7.1 channels
Component for: PC
Motherboard form factor: ATX
PC health monitoring: Fan, Temperature, Voltage, Water cooling
Windows operating systems supported: Windows 11 x64
Motherboard chipset family: AMD
Parallel processing technology support: Not supported
HDCP: Yes
HDCP version: 2.3
DirectX version: 12.0
Maximum resolution: 5120 x 2880 pixels
USB 2.0 connectors: 2
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 0
Number of SATA III connectors: 4
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
CPU fan connector: Yes
EPS power connector (8-pin): Yes
Front panel connector: Yes
Number of CPU fan connectors: 2
Number of chassis fan connectors: 4
Number of water pump connectors: 2
RGB LED pin header: Yes
Number of RGB LED pin headers: 4
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of EPS power connectors (8-pin): 1
12V power connector: Yes
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
Supported memory clock speed (max): 3200 MHz
Maximum internal memory per slot: 32 GB
Supported memory clock speeds: 3200,2933,2667,2400,2133 MHz
ECC сompatibility: ECC & Non-ECC
Supported memory types: DDR4-SDRAM
Number of memory slots: 4
Memory slots type: DIMM
Unbuffered memory: Yes
Memory channels: Dual-channel
Maximum internal memory: 128 GB
Ethernet LAN: Yes
Wi-FI: No
Ethernet interface type: 2.5 Gigabit Ethernet
LAN controller: Realtek RTL8125
Weight: 2.04 kg
Batteries included: Yes
Bundled software: Norton® Internet Security (OEM version)
Screws included: Yes
Package width: 335 mm
Package depth: 270 mm
Package height: 80 mm
Package weight: 2.47 kg
Compatible processor series: AMD Ryzen 5000 Series, AMD Ryzen 4000 Series, AMD Ryzen 3000 Series
Processor socket: Socket AM4
Processor manufacturer: AMD
Supported processor sockets: Socket AM4
DVI-D ports quantity: 0
USB 2.0 ports quantity: 2
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Line-in: Yes
DisplayPort version: 1.4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
HDMI ports quantity: 1
HDMI version: 2.1
S/PDIF out port: Yes
Digital audio optical out: 1
DisplayPorts quantity: 1
VGA (D-Sub) ports quantity: 0
Ethernet LAN (RJ-45) ports: 1
Headphone outputs: 1
Supported storage drive interfaces: M.2, PCI Express 4.0, PCI Express 3.0, SATA III
Supported storage drive types: HDD & SSD
RAID support: Yes
RAID levels: 0, 1, 10
Number of storage drives supported: 6
Number of HDDs supported: 4
Warranty period: 3 year(s)
Height: 35 mm
Width: 305 mm
Depth: 244 mm
