Sursa Spacer ATX BZCO-550 550W

Sursa Spacer ATX BZCO-550 80+ Bronze compatible, 550w, fan 120mm, 2x PCI-E (6+2), 6x S-ATA, 2x P8 (4+4), „SPPS-BZCO-550”
Garantie: 24 luni


Specificatii tehnice

20+4 Pin ATX: 1
SATA: 6
6+2 PCI-E: 2
4+4 Pin ATX/EPS: 2
Molex: 3
Floppy: 1
Fan diameter: 12 cm
Recomandat Gaming: Nu
Numar de ventilatoare: 1x 120 mm
Sursa Modulara: Nu
Certificare: 80+ Bronze
Permite Asamblare: Standard
Permite Wire Management: Da
Voltaj/Amperaj: 200 - 240V, 4A, 50Hz
Tip sursa: ATX 12V 2.31
Dimensiuni: 275 x 195 x 105 mm
Greutate: 1410 g
Putere Sursa: 550 W
Power supply unit (PSU) form factor: ATX
Purpose: PC
80 PLUS certification: 80 PLUS Bronze
ATX version: 2.31
Motherboard power connector: 20+4 pin ATX
CPU power connector (4+4 pin): Yes
ATX power connector (20+4 pin): Yes
PCI Express connector: Yes
Number of SATA power connectors: 5
PCI Express power connectors (6+2 pin): 2
Total power: 550 W
Max output current (+3.3V): 18 A
AC input frequency: 50 Hz
AC input voltage: 200 - 240 V
Combined power (+3.3V): 100 W
Combined power (+5V): 100 W
Combined power (+5Vsb): 12.5 W
Max output current (+5Vsb): 2.5 A
Max output current (-12V): 0.5 A
Input current: 4 A
Combined power (-12V): 6 W
Max output current (+12V1): 29 A
Max output current (+12V2): 29 A
Max output current (+5V): 19 A
-12V: 0.3 A
Rail +12V: 1
+5V: 16 A
+3.3V: 14 A
+5Vsb: 3 A
+12V 1: 42 A
PFC: Active
Warranty period: 2 year(s)
