SURSA NJOY ALPHA+ 750W

Sursa NJOY ALPHA+ 750W 80+ GOLD, ATX, Active PFC, Modulara, Protectie OVP / OCP / OTP / UVP / SCP / OPP, Tehnologie Zero Fan, negru
Garantie: 24 luni


Specificatii tehnice

Certification: CE, RoHS
Product colour: Black
Fan diameter: 12 cm
Cooling type: Active
Number of fans: 1 fan(s)
Fan location: Top
Master (outer) case width: 590 mm
Master (outer) case length: 450 mm
Master (outer) case height: 275 mm
Master (outer) case net weight: 16.8 kg
Master (outer) case gross weight: 18.3 kg
Products per master (outer) case: 8 pc(s)
Cables included: AC, PATA, PCIe, SATA
Package depth: 280 mm
Package height: 12.5 mm
Package type: Box
Package width: 215 mm
Package weight: 21 kg
Bearing technology: Hydraulic
Power supply unit (PSU) form factor: ATX
80 PLUS certification: 80 PLUS Gold
Purpose: PC
Motherboard power connector: 20+4 pin ATX
CPU power connector (4+4 pin): Yes
Peripheral (Molex) power connectors (4-pin): 3
Motherboard power cable length: 60 cm
Cabling type: Fully-Modular
PCI Express power connectors (6+2 pin): 2
CPU power cable length: 55 cm
Number of PATA power connectors: 6
SATA power cable length: 150,450 mm
Peripheral (Molex) power cable length: 150,450 mm
PCI Express power connectors (12-pin): 1
PCI Express power cable length: 60 cm
Power protection features: Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage
Power Factor Correction (PFC) type: Active
Max output current (+3.3V): 20 A
Max output current (+5V): 20 A
Total power: 750 W
Combined power (+12V): 750 W
Combined power (+5Vsb): 15 W
Max output current (+12V): 62.5 A
Max output current (+5Vsb): 3 A
Combined power (+3.3V): 100 W
Combined power (+5V): 100 W
Combined power (-12V): 3.6 W
Max output current (-12V): 0.3 A
AC input voltage: 100 - 240 V
AC input frequency: 50/60 Hz
Width: 145 mm
Weight: 1.71 kg
Depth: 150 mm
Height: 86 mm
