MB MSI MAG Z790 TOMAHAWK WIFI D5 LGA1700

Placa de baza MSI MAG Z790 TOMAHAWK WIFI DDR5 LGA 1700 SPECIFICATIONS Model Name MAG Z790 TOMAHAWK WIFI CPU Support Supports 12th/ 13th Gen Intel® Core™ Processors, Pentium® Gold and Celeron® Processors CPU Socket LGA 1700 Chipset Intel® Z790 Chipset Expansion Slots 1x PCIe 5.0 x16 slot, 1x PCIe 4.0 x16 slot, 1x PCIe 3.0 x1 slot Display Interface Support 4K@60Hz as specified in HDMI™ 2.1, DisplayPort 1.4 – Requires Processor Graphics Memory Support 4 DIMMs, Dual Channel DDR5 7200+MHz (OC) Storage 4x M.2 Gen4 x4 64Gbps slots, 7x SATA 6Gb/s ports USB ports 1x USB 3.2 Gen 2x2 20Gbps (Type-C), 6x USB 3.2 Gen 2 10Gbps (4 Type-A + 2 Type-C), 6x USB 3.2 Gen 1 5Gbps (Type-A), 4x USB 2.0 LAN 1x Intel® 2.5Gbps LAN Wireless / Bluetooth Intel® Wi-Fi 6E, Bleutooth 5.2 Audio 8-Channel (7.1) HD Audio with Audio Boost 5
Garantie: 36 luni


Specificatii tehnice

BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
ACPI version: 6.4
System Management BIOS (SMBIOS) version: 3.5
PCI Express x1 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 4
PCI Express x16 (Gen 5.x) slots: 2
Motherboard chipset: Intel Z790
Motherboard form factor: ATX
Motherboard chipset family: Intel
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Audio output channels: 7.1 channels
Component for: PC
Parallel processing technology support: Not supported
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
Front panel connector: Yes
TPM connector: Yes
RGB LED pin header: Yes
Chassis intrusion connector: Yes
Number of SATA III connectors: 7
USB 2.0 connectors: 2
Number of SATA II connectors: 0
Number of SATA connectors: 0
Front panel audio connector: Yes
CPU fan connector: Yes
Number of memory slots: 4
Unbuffered memory: Yes
Supported memory types: DDR5-SDRAM
Maximum internal memory: 192 GB
Memory channels: Dual-channel
Supported memory clock speeds: 4800,5200,5400,5600,5800,6000,6200,6400,6600,6800,7000,7200 MHz
ECC сompatibility: Non-ECC
Supported memory clock speed (max): 7200 MHz
Ethernet interface type: 2.5 Gigabit Ethernet
Bluetooth version: 5.3
Wi-Fi standards: 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax)
Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
Wi-FI: Yes
Ethernet LAN: Yes
Cables included: SATA
Processor socket: LGA 1700
Supported processor sockets: LGA 1700
Maximum internal memory supported by processor: 192 GB
Compatible processor series: Intel® Celeron®, Intel® Pentium® Gold
Processor manufacturer: Intel
DisplayPort version: 1.4
HDMI ports quantity: 1
HDMI version: 2.1
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
USB 3.2 Gen 2x2 Type-C ports quantity: 1
USB 2.0 ports quantity: 0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
DisplayPorts quantity: 1
VGA (D-Sub) ports quantity: 0
S/PDIF out port: Yes
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
RAID levels: 0, 5, 10
RAID support: Yes
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, PCI Express
Width: 243.8 mm
Depth: 304.8 mm
Onboard-CPU: No
PCI: 0
Serial-or-Paralel: No/No
