UPS NJOY BALDER 10000 PWUP-OL10KBA-AZ01B

UPS nJoy Balder 10000, 10000VA/10000 W, On-line, LCD Display, Management, Rack/Tower, Dubla conversie, 2U, Nu are baterie inclusa, PWUP-OL10KBA-AZ01B
Garantie: 36 luni


Specificatii tehnice

Charging current: 4 A
Battery voltage: 12 V
Battery technology: Lead-Acid
Certification: CE, RoHS
Display type: LCD
Control type: Buttons
Form factor: Rackmount/Tower
Rack capacity: 2U
Auto-restart: Yes
UPS topology: Double-conversion (Online)
Crest factor: 3:1
Waveform: Pure sine
Output operation voltage (min): 208 V
Input operation voltage (min): 110 V
Power factor: 0.99
Output voltage Total Harmonic Distortion (THD): 4%
Power protection features: Overcharge, Overdischarge, Overheating, Overload
Surge energy rating: 600 J
Output power capacity: 10 kVA
Output power: 10000 W
Input frequency: 46/54 Hz
Output frequency: 46/54 Hz
Input current Total Harmonic Distortion (THD): 6%
Number of input phases: 1
Input operation voltage (max): 300 V
Output operation voltage (max): 240 V
Emergency Power Off (EPO): Yes
Response time: 4 ms
Surge protection: Yes
Noise level: 55 dB
Master (outer) case height: 240 mm
Master (outer) case net weight: 17 kg
Master (outer) case gross weight: 21 kg
Products per master (outer) case: 1 pc(s)
Master (outer) case width: 565 mm
Master (outer) case length: 700 mm
Operating temperature (T-T): 0 - 40 °C
Operating relative humidity (H-H): 0 - 95%
RS-232 ports: 1
Width: 438 mm
Height: 88 mm
Weight: 17 kg
Rackable: No
UPS-Management: Yes
