Omada 20Port Gigabit 16-Port PoE+ Switch

Compliance certificates: CE, Federal Communications Commission (FCC), RoHS

Packet buffer memory: 4 MB

Store-and-forward: Yes

Jumbo frames: 15

Jumbo frames support: Yes

MAC address table: 8000 entries

Switching capacity: 20 Gbit/s

Forwarding rate: 14.88 Mpps

Stackable: No

Reset button: Yes

Product colour: Black

Wall mountable: Yes

Networking standards: IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3at, IEEE 802.3x

VLAN support: Yes

Quality of Service (QoS) support: Yes

Flow control support: Yes

Switch type: Managed

Cloud-managed: Yes

Virtual LAN features: MTU VLAN, Port-based VLAN, Tagged VLAN

Power over Ethernet (PoE): Yes

Link aggregation: Yes

Port mirroring: Yes

Auto MDI/MDI-X: Yes

Auto-negotiation: Yes

10G support: No

Storage relative humidity (H-H): 5 - 90%

Operating temperature (T-T): 0 - 40 °C

Operating relative humidity (H-H): 10 - 90%

Storage temperature (T-T): -40 - 70 °C

Transmission distance (max): 0.25 km

User guide: Yes

Cables included: AC

Package type: Box

Fanless: Yes

Basic switching RJ-45 Ethernet ports quantity: 10

Basic switching RJ-45 Ethernet ports type: Gigabit Ethernet (10/100/1000)

Combo SFP ports quantity: 1

Input current: 2.43 A

DC input voltage: 53.5 V

Power source: DC

Power supply included: Yes

Power over Ethernet plus (PoE+) ports quantity: 8

Power over Ethernet (PoE) power per port: 30 W

Total Power over Ethernet (PoE) budget: 123 W

DHCP features: DHCP client

IGMP snooping: Yes

Height: 26 mm

Depth: 126 mm

Width: 209 mm

Rackable: No

LAN-Port-Type: FastEthernet

LAN-Ports: 8

Redundant-PSU: No

Garantia Produsului: 36 luni
