Intel Core i5-14600K processor

Intel Core i5-14600K. Processor family: Intel® Core™ i5, Processor socket: LGA 1700, Package type: Tray. Memory channels: Dual-channel, Maximum internal memory supported by processor: 192 GB, Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM. On-board graphics card model: Intel UHD Graphics 770, On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1, On-board graphics card base frequency: 300 MHz. Market segment: Desktop, Use conditions: Workstation, PC/Client/Tablet, PCI Express slots version: 4.0, 5.0. Processor package size: 45 x 37.5 mm
Garantie: 24 luni


Specificatii tehnice

CPU configuration (max): 1
Embedded options available: No
Execute Disable Bit: Yes
Idle States: Yes
Thermal Monitoring Technologies: Yes
Maximum number of PCI Express lanes: 20
PCI Express configurations: 1x16+1x4, 2x8+1x4
Scalability: 1S
Direct Media Interface (DMI) Revision: 4.0
Export Control Classification Number (ECCN): 5A992C
Commodity Classification Automated Tracking System (CCATS): 740.17B1
Supported instruction sets: AVX 2.0, SSE4.1, SSE4.2
Market segment: Desktop
PCI Express slots version: 4.0, 5.0
Thermal solution specification: PCG 2020A
Use conditions: Workstation, PC/Client/Tablet
On-board graphics card ID: 0xA780
On-board graphics card outputs supported: Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card base frequency: 300 MHz
On-board graphics card dynamic frequency (max): 1550 MHz
Number of displays supported (on-board graphics): 4
On-board graphics card maximum resolution (DisplayPort): 7680 x 4320 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel): 5120 x 3200 pixels
On-board graphics card maximum resolution (HDMI): 4096 x 2160 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort): 60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel): 120 Hz
On-board graphics card refresh rate at maximum resolution (HDMI): 60 Hz
Number of execution units: 32
Multi-Format Codec Engines: 2
On-board graphics card model: Intel UHD Graphics 770
On-board graphics card DirectX version: 12.0
On-board graphics card OpenGL version: 4.5
On-board graphics card: Yes
Discrete graphics card: No
Discrete graphics card model: Not available
Harmonized System (HS) code: 8542310001
Maximum internal memory supported by processor: 192 GB
Memory types supported by processor: DDR4-SDRAM, DDR5-SDRAM
Memory bandwidth (max): 89.6 GB/s
Memory channels: Dual-channel
Tjunction: 100 °C
Maximum internal memory: 192 GB
Graphics output: eDP 1.4b, DP 1.4a, HDMI 2.1
L2 cache: 20480 KB
Performance-core boost frequency: 5.3 GHz
Processor model: i5-14600K
Processor ARK ID: 236799
Package type: Tray
Performance-core base frequency: 3.5 GHz
Stepping: B0
Processor socket: LGA 1700
Efficient-core base frequency: 2.6 GHz
Maximum turbo power: 181 W
Maximum number of DMI lanes: 8
Memory bandwidth supported by processor (max): 89.6 GB/s
Processor codename: Raptor Lake
Processor family: Intel® Core™ i5
Processor boost frequency: 5.3 GHz
Processor threads: 20
Processor generation: Intel® Core™ i5 (14th gen)
Processor base power: 125 W
Processor manufacturer: Intel
Efficient cores: 8
Processor cache type: Smart Cache
Performance cores: 6
Processor cache: 24 MB
Efficient-core boost frequency: 4 GHz
Processor operating modes: 64-bit
Processor cores: 14
Intel Virtualization Technology for Directed I/O (VT-d): Yes
Intel Virtualization Technology (VT-x): Yes
Intel VT-x with Extended Page Tables (EPT): Yes
Intel® Hyper Threading Technology (Intel® HT Technology): Yes
Enhanced Intel SpeedStep Technology: Yes
Intel® Quick Sync Video Technology: Yes
Intel® AES New Instructions (Intel® AES-NI): Yes
Intel® Secure Key: Yes
Intel® OS Guard: Yes
Intel 64: Yes
Intel® Turbo Boost Technology: 2.0
Intel® Clear Video HD Technology (Intel® CVT HD): Yes
Intel® Speed Shift Technology: Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0: Yes
Intel® Control-flow Enforcement Technology (CET): Yes
Intel® Thread Director: Yes
Intel® Boot Guard: Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
Intel® Volume Management Device (VMD): Yes
Mode-based Execute Control (MBE): Yes
Intel® Standard Manageability (ISM): Yes
OpenCL version: 3.0
Status: Launched
Launch date: Q4'23
Processor package size: 45 x 37.5 mm
