UPS NJOY ECHO PRO 3000

Typical backup time at full load: 1 min

Typical backup time at half load: 7 min

Replacement battery cartridge: GP07122L

Battery recharge time: 4 h

Number of batteries supported: 6

Compliance certificates: CE, RoHS

Control type: Buttons

LED indicators: Yes

Display type: LCD

Built-in fan: Yes

Form factor: Tower

Cooling type: Active

Response time: 4 ms

Input frequency: 50 - 60 Hz

Surge protection: Yes

Output frequency: 50/60 Hz

Number of input phases: 1

Number of output phases: 1

Output power capacity: 3 kVA

Auto-restart: Yes

UPS topology: Double-conversion (Online)

Crest factor: 3:1

Output power: 2400 W

Waveform: Pure sine

Input operation voltage (min): 80 V

Output operation voltage (min): 208 V

Surge energy rating: 565 J

Efficiency: 85%

Efficiency (On-line mode): 88%

Efficiency (ECO mode): 96%

Total Harmonic Distortion (THD) (linear load): 3%

Total Harmonic Distortion (THD) (non-linear load): 5%

Output operation voltage (max): 240 V

Output power factor: 0.8

Emergency Power Off (EPO): Yes

Input operation voltage (max): 300 V

Noise level: 40 dB

Products per master (outer) case: 1 pc(s)

Master (outer) case net weight: 21.3 kg

Master (outer) case width: 295 mm

Master (outer) case length: 519 mm

Master (outer) case height: 458 mm

Master (outer) case gross weight: 22.1 kg

Operating temperature (T-T): 0 - 40 °C

Operating relative humidity (H-H): 0 - 90%

Batteries included: Yes

Package width: 295 mm

Package depth: 519 mm

Package height: 458 mm

Package weight: 22.1 kg

Package type: Box

AC outlet types: Type F

Serial interface type: RS-232

AC outlets quantity: 3 AC outlet(s)

USB port type: USB Type-B

Serial interface: Yes

RS-232 ports: 1

USB 2.0 ports quantity: 1

Sustainability compliance: Yes

Width: 196 mm

Depth: 416 mm

Height: 342 mm

Weight: 21.3 kg

Garantia Produsului: 36 luni
