SOCOMEC ITYS 1000VA VFI UPS 1/1 PF=1 WI

Battery capacity: 7 Ah

Typical backup time at full load: 7.8 min

Charging current: 8 A

Battery technology: Sealed Lead Acid (VRLA)

Battery life (max): 3 year(s)

Battery voltage: 3.6 V

Certification: IEC/EN 62040-2, AS 62040.2nIEC/EN 62040-3nCE, RCM (E2376)

Product colour: Black, Grey, Orange

Control type: Buttons

International Protection (IP) code: IP20

LED indicators: Yes

Display type: LCD

Form factor: Mini Tower

ECO mode: Yes

Output frequency: 50/60 Hz

Number of input phases: 1

Number of output phases: 1

Efficiency (ECO mode): 98%

UPS topology: Double-conversion (Online)

Input frequency: 40 - 70 Hz

Crest factor: 3:1

Output operation voltage (min): 200 V

Efficiency: 93%

Input power factor: 0.99

Waveform: Sine

Input operation voltage (max): 300 V

Output operation voltage (max): 240 V

Emergency Power Off (EPO): Yes

Output power capacity: 1 kVA

Input operation voltage (min): 160 V

Output power: 1000 W

Output power factor: 1

Power protection features: Short circuit

Noise level: 50 dB

Country of origin: China

Operating temperature (T-T): 0 - 45 °C

Operating relative humidity (H-H): 0 - 95%

Operating altitude: 0 - 1000 m

AC outlets quantity: 4 AC outlet(s)

AC outlet types: C13 coupler

Power plug: C14 coupler

USB port type: USB Type-B

RS-232 ports: 1

Safety: IEC/EN 62040-1, AS 62040.1.1, AS 62040.1.2

Height: 224 mm

Width: 145 mm

Weight: 14.4 kg

Depth: 40.4 mm

Garantia Produsului: 24 luni
