MB Asrock X870 PRO RS AM5

Placa de Baza ASROCK X870 PRO RS AM5, 4x DDR5, 1x HDMI 2x USB4, 1x PCIE 5.0 x16 1x PCIE 4.0 x16, 4x M.2, 4x SATA 6GB/s, ATX
Garantie: 36 luni


Specificatii tehnice

BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
Number of M.2 (M) slots: 3
1st M.2 highest PCI Express generation: 5.0
2nd M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2280
2nd M.2 largest key size: 2280
3rd M.2 largest key size: 2280
3rd M.2 highest PCI Express generation: 3.0
PCI Express x16 (Gen 5.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
Audio output channels: 7.1 channels
Component for: PC
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard chipset: AMD X870
Audio Chip: Realtek ALC1220
Motherboard chipset family: AMD
Motherboard form factor: ATX
Product colour: White
Power source type: ATX
Certification: FCC, CEnErP/EuP ready (ErP/EuP ready power supply is required)
Parallel processing technology support: Crossfire
HDCP: Yes
Maximum resolution: 7680 x 4320 pixels
USB 2.0 connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 0
Number of SATA III connectors: 4
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
CPU fan connector: Yes
EPS power connector (8-pin): Yes
USB 3.2 Gen 2x2 connectors: 1
Number of CPU fan connectors: 2
Number of chassis fan connectors: 4
Number of EPS power connectors (8-pin): 2
RGB LED pin header: Yes
Number of RGB LED pin headers: 5
Number of water pump connectors: 1
Number of temperature sensor headers: 1
Supported memory clock speed (max): 8000 MHz
Supported memory types: DDR5-SDRAM
Maximum internal memory: 256 GB
ECC сompatibility: ECC & Non-ECC
Number of memory slots: 4
Memory slots type: DIMM
Unbuffered memory: Yes
Memory channels: Dual-channel
Ethernet LAN: Yes
Wi-FI: No
Ethernet interface type: 2.5 Gigabit Ethernet
LAN controller: Dragon RTL8125BG
Number of M.2 (E) slots: 1
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Processor socket: Socket AM5
Processor manufacturer: AMD
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
HDMI ports quantity: 1
HDMI version: 2.1
DVI-D ports quantity: 0
Digital audio optical out: 1
VGA (D-Sub) ports quantity: 0
S/PDIF out port: Yes
USB 2.0 ports quantity: 6
USB4 Gen 2x2 ports quantity: 2
Microphone in: Yes
Headphone outputs: 1
Supported storage drive interfaces: PCI Express 3.0, PCI Express 4.0, PCI Express 5.0, SATA III
RAID levels: 0, 1, 10
Number of HDDs supported: 4
Number of storage drives supported: 7
RAID support: Yes
Supported storage drive types: HDD & SSD
Width: 30.5 mm
Depth: 24.4 mm
USB3: 4-8
Onboard-CPU: No
PCI: 0
Serial-or-Paralel: No/No
MB-Format: ATX
PCI-Ex1: 0
RAM-Slots: 4
MB-Socket: AM5
PCI-Ex16: 2
