MB ASROCK B550M-HDV AM4

Placa de baza AsRock B550M-HDV AM4 Supports AMD AM4 Socket Ryzen™ 3000, 4000 G-Series and 5000 Series Desktop Processors 6 Power Phase Design Supports DDR4 4733+ (OC) 1 PCIe 4.0 x16, 1 PCIe 3.0 x1 Graphics Output Options: HDMI, DVI-D, D-Sub 7.1 CH HD Audio (Realtek ALC887 Audio Codec) 4 SATA3, 1 Hyper M.2 (PCIe Gen4 x4 & SATA3) 6 USB 3.2 Gen1 (2 Front, 4 Rear) Gigabit LAN https://www.asrock.com/MB/AMD/B550M-HDV/index.asp#Specification
Garantie: 24 luni


Specificatii tehnice

BIOS type: UEFI AMI
Motherboard form factor: micro ATX
Motherboard chipset family: AMD
Audio Chip: Realtek ALC887
Component for: PC
Audio output channels: 7.1 channels
Motherboard chipset: AMD B550
On-board graphics card: Yes
HDCP: Yes
DirectX version: 12.0
Graphics card family: AMD
Graphics card: Radeon Vega
USB 2.0 connectors: 4
Peripheral (Molex) power connectors (4-pin): 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
TPM connector: Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 0
Number of SATA III connectors: 4
Number of SATA II connectors: 0
Number of Parallel ATA connectors: 0
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
CPU fan connector: Yes
Number of chassis fan connectors: 2
Harmonized System (HS) code: 84733020
ECC сompatibility: ECC & Non-ECC
Memory slots type: DIMM
Unbuffered memory: Yes
Number of memory slots: 2
Supported memory types: DDR4-SDRAM
Memory channels: Dual-channel
Maximum internal memory: 64 GB
Wake-on-LAN ready: Yes
Ethernet interface type: Gigabit Ethernet
Wi-FI: No
LAN controller: Realtek RTL8111H
Ethernet LAN: Yes
Weight: 465 g
Drivers included: Yes
Compatible processor series: AMD Ryzen 3000 Series
Processor socket: Socket AM4
Processor manufacturer: AMD
Maximum number of SMP processors: 1
eSATA ports quantity: 0
Firewire (IEEE 1394) ports: 0
USB 2.0 ports quantity: 2
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 0
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
DVI-D ports quantity: 1
HDMI ports quantity: 1
VGA (D-Sub) ports quantity: 1
PS/2 ports quantity: 1
Supported storage drive interfaces: M.2, SATA III
Width: 230 mm
Height: 70 mm
Depth: 201 mm
CPU încorporat: No
PCI: 0
Serial-or-Paralel: No/No
