TPL MC WDM GB TO FO SM SC 20KM TYPE B

Compliance certificates: RoHS

Certification: FCC, CE

LED indicators: Yes

Product colour: Black

Internal: No

Harmonized System (HS) code: 85176990

Cable types supported: Cat3, Cat4, Cat5

Ethernet interface type: Gigabit Ethernet

Fiber ethernet cabling technology: 100BASE-FX

Ethernet LAN data rates: 10,100 Mbit/s

Auto MDI/MDI-X: Yes

Maximum data transfer rate: 100 Mbit/s

Networking standards: IEEE 802.3, IEEE 802.3u

Duplex system: Full, Half

Copper ethernet cabling technology: 10BASE-TX, 100BASE-FX, 100BASE-TX

Storage relative humidity (H-H): 5 - 90%

Storage temperature (T-T): -40 - 70 °C

Operating temperature (T-T): 0 - 40 °C

Operating relative humidity (H-H): 10 - 90%

Package width: 165 mm

Package height: 65 mm

Package depth: 204 mm

Package weight: 360 g

Wavelength: 1550 nm

Fiber ports quantity: 1

Fiber optic connector: SC

Maximum transfer distance: 20000 m

Wavelength-division multiplexing (WDM): Yes

Fiber mode structure: Single-mode

Connectivity technology: Wired

Ethernet LAN (RJ-45) ports: 1

Power consumption (max): 2.41 W

Height: 27 mm

Width: 95 mm

Depth: 73 mm

MC-Standard: FastEthernet

MC-Type: Single mode

Garantia Produsului: 60 luni
