MB GIGABYTE Z890 AORUS ULTRA

Placa de Baza GIGABYTE Z890 AORUS ULTRA LGA1851, 2x DDR5, 1x Intel Thunderbolt 1x DP 1x HDMI, 1x PCIE x16, 2x M.2, 2x SATA III, Mini-ITX
Garantie: 36 luni


Specificatii tehnice

Lithium weight per battery: 0.07 g
Battery weight: 3 g
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
ACPI version: 5.0
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
Clear CMOS button: Yes
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
Clear CMOS jumper: Yes
Number of M.2 (M) slots: 2
PCI Express x16 slots: 1
Component for: PC
Audio output channels: 7.1 channels
Motherboard chipset: Intel Z890
Motherboard chipset family: Intel
Windows operating systems supported: Windows 11 x64
PC health monitoring: Fan, Temperature, Voltage
Motherboard form factor: mini ITX
Product colour: Black
DirectX version: 12.0
Total number of SATA connectors: 2
Number of SATA III connectors: 2
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
ATX Power connector (24-pin): Yes
EPS power connector (8-pin): Yes
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
TPM connector: Yes
RGB LED pin header: Yes
USB 2.0 connectors: 1
12V power connector: Yes
Country of origin: China
Products per shipping (inner) case: 1 pc(s)
Supported memory clock speeds: 5600,5800,6000,6200,6400,6600,6800,7000,7200,7400,7600,7800,7900,7950,8000,8200,8266,8400,8600 MHz
Supported memory clock speed (max): 8800 MHz
Supported memory module capacities: 1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 24GB, 32GB, 40GB, 48GB, 64GB
ECC сompatibility: Non-ECC
Memory channels: Dual-channel
Memory slots type: DIMM
Number of memory slots: 2
Supported memory types: DDR5-SDRAM
Maximum internal memory: 256 GB
Wi-FI: Yes
Ethernet LAN: Yes
Top Wi-Fi standard: Wi-Fi 7 (802.11be)
Ethernet interface type: 2.5 Gigabit Ethernet
WLAN controller model: Intel Wi-Fi 7 BE202
Bluetooth: Yes
Wi-Fi standards: Wi-Fi 7 (802.11be)
Bluetooth version: 5.4
Weight: 14.2 kg
Bundled software: Norton® Internet Security (OEM version)rnLAN bandwidth management software
Batteries included: Yes
Package width: 265 mm
Package depth: 235 mm
Package height: 97 mm
Package weight: 16.4 kg
Maximum internal memory supported by processor: 256 GB
Compatible processor series: Intel Core Ultra (Series 2)
Processor manufacturer: Intel
Processor socket: LGA 1851 (Socket V1)
Supported processor sockets: LGA 1851
S/PDIF out port: Yes
DisplayPorts quantity: 1
VGA (D-Sub) ports quantity: 0
DVI-D ports quantity: 0
USB 2.0 ports quantity: 0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
HDMI ports quantity: 1
Thunderbolt ports quantity: 1
Microphone in: Yes
Ethernet LAN (RJ-45) ports: 1
RAID support: Yes
Number of storage drives supported: 2
Supported storage drive types: HDD & SSD
Supported storage drive interfaces: M.2, SATA III
Number of HDDs supported: 4
RAID levels: 0, 1, 5, 10
Warranty period: 3 year(s)
Height: 35 mm
Width: 170 mm
Depth: 170 mm
Onboard-CPU: No
PCI: 0
Serial-or-Paralel: Yes/No
