MB Gigabyte B650M GAMING PLUS WF AM5

Placa de Baza GIGABYTE B650M GAMING PLUS WIFI AM5, 4x DDR5, 2x DP 1x HDMI, 1x PCIE 4.0 x16 1x PCIE 3.0 x1, 2x M.2, 4x SATA 6GB/s, mATX
Garantie: 36 luni


Specificatii tehnice

Lithium weight per battery: 0.07 g
Battery weight: 3 g
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
ACPI version: 5.0
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
Clear CMOS jumper: Yes
HDMI: 1
RJ-45: 1
DisplayPort: 2
USB 2.0: 2
USB Tip C: 1
Suport audio: 7.1
Conectori speciali: 2 x conectori antena 2T2R
USB 3.2 Gen1 tip A: 3
Audio jacks: 3
PS/2 Combo Mouse/Tastatura: 1
1st M.2 highest PCI Express generation: 4.0
1st M.2 largest key size: 2580
PCI Express x1 (Gen 3.x) slots: 1
PCI Express x16 (Gen 4.x) slots: 1
Number of M.2 (M) slots: 2
2nd M.2 largest key size: 22110
2nd M.2 highest PCI Express generation: 4.0
Motherboard form factor: micro ATX
Motherboard chipset family: AMD
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Cooling type: Passive
Audio output channels: 7.1 channels
Audio Chip: Realtek ALC897
Component for: PC
PC health monitoring: Fan, Temperature, Voltage
Motherboard chipset: AMD B650
Product colour: Dark brown
Power source type: ATX
Recomandat Gaming: Da
Chipset audio: Realtek ALC897
Chipset retea: Realtek RTL8125BG
BIOS: 256 Mbit AMI UEFI BIOS
Interfata grafica: PCI Express x16 4.0
RAID: 0, 1, 10
Placa retea integrata: 2.5 Gbps
Placa video integrata: Necesita procesor cu tehnologia AMD Radeon Graphics
Placa audio integrata: 7.1 Audio
NGFF (M.2): 2
SATA III: 4
HDCP: Yes
Parallel processing technology support: Not supported
DirectX version: 12.0
Maximum resolution: 4096 x 2160 pixels
USB 2.0 connectors: 2
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 0
Number of SATA III connectors: 4
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
CPU fan connector: Yes
Number of chassis fan connectors: 2
EPS power connector (8-pin): Yes
Front panel connector: Yes
TPM connector: Yes
RGB LED pin header: Yes
Number of EPS power connectors (8-pin): 1
Number of CPU fan connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
Number of RGB LED pin headers: 3
Sloturi memorie: 4
Model memorie: DDR5
Capacitate maxima memorie RAM: 256 GB
Tehnologie: Dual channel
Frecvente suportate: 8000(OC)/ 7800(OC)/ 7600(OC)/ 7200(OC)/ 7000(OC)/ 6800(OC)/ 6600(OC)/ 6400(OC)/ 6200(OC)/ 6000(OC)/ 5600(OC)/ 5200/ 4800 MHz
Alte specificatii: Suporta profil de memorie Intel XMP
AMD EXPO
Supported memory clock speed (max): 8000 MHz
Supported memory clock speeds: 8000,7800,7600,7200,7000,6800,6600,6400,6200,6000,5600,5200,4800 MHz
ECC сompatibility: Non-ECC
Number of memory slots: 4
Memory slots type: DIMM
Unbuffered memory: Yes
Supported memory types: DDR5-SDRAM
Maximum internal memory: 256 GB
Maximum internal memory per slot: 64 GB
Memory channels: Dual-channel
Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Ethernet LAN: Yes
Wi-FI: Yes
WLAN controller model: Realtek RTL8852CE
Ethernet interface type: 2.5 Gigabit Ethernet
LAN controller: Realtek RTL8125
Bluetooth version: 5.3
Bluetooth: Bluetooth 5.3
Weight: 1.44 kg
Bundled software: Norton® Internet Security (OEM version)rnLAN bandwidth management software
Antenna included: Yes
Screws included: Yes
Package height: 68 mm
Package width: 270 mm
Package depth: 268 mm
Package weight: 1.53 kg
Producator chipset: AMD
Procesoare suportate: AMD Ryzen 7000/8000/9000 Series
CPU Socket: AM5
Chipset: B650
Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
Processor socket: Socket AM5
Supported processor sockets: Socket AM5
Processor manufacturer: AMD
USB 2.0 ports quantity: 2
DisplayPort version: 1.4
HDMI ports quantity: 1
HDMI version: 2.1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
VGA (D-Sub) ports quantity: 0
DVI-D ports quantity: 0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 0
DisplayPorts quantity: 2
Line-in: Yes
WiFi-AP antenna jack: 2
PS/2 ports quantity: 1
Microphone in: Yes
Headphone outputs: 1
PCI Express x1: 2
PCI Express 4.0: 1 (x16)
Header USB 3.0: Da
Format: mATX
Dimensiuni (L x l, cm): 24.4 x 24.4 cm
RAID levels: 0, 1, 10
Number of HDDs supported: 4
Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
Number of storage drives supported: 6
Supported storage drive types: HDD & SSD
RAID support: Yes
Height: 35 mm
Width: 244 mm
Depth: 24.4 mm
MB-Socket: AM5
RAM-Slots: 4
MB-Format: micro-ATX
PCI: 0
Serial-or-Paralel: No/No
USB3: 4-8
PCI-Ex1: 1
PCI-Ex16: 1
Onboard-CPU: No
