MB GIGABYTE A620M DS3H DDR5

MB GIGABYTE A620M DS3H (rev. 1.0) AM5 4xDDR5 1x Display Port, 1x HDMI, 1x D-Sub, Micro ATX https://www.gigabyte.com/Motherboard/A620M-DS3H-rev-10/sp#sp
Garantie: 36 luni


Specificatii tehnice

Lithium weight per battery: 0.07 g
Battery weight: 3 g
Number of battery cells: 1
Battery technology: Lithium-Manganese Dioxide (LiMnO2)
Battery type: CR2032
ACPI version: 5.0
Desktop Management Interface (DMI) version: 2.7
System Management BIOS (SMBIOS) version: 2.7
BIOS type: UEFI AMI
BIOS memory size: 256 Mbit
Clear CMOS jumper: Yes
PCI Express x16 slots: 1
Number of M.2 (M) slots: 1
PCI Express x1 slots: 1
Audio output channels: 7.1 channels
Component for: PC
Windows operating systems supported: Windows 10 x64, Windows 11 x64
Motherboard form factor: micro ATX
Motherboard chipset family: AMD
Product colour: Brown
Motherboard chipset: AMD A620
PC health monitoring: Fan, Temperature, Voltage, Water cooling
HDCP: Yes
Parallel processing technology support: Not supported
DirectX version: 12.0
Maximum resolution: 4096 x 2160 pixels
Front panel connector: Yes
TPM connector: Yes
RGB LED pin header: Yes
Total number of SATA connectors: 4
12V power connector: Yes
USB 2.0 connectors: 1
USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
USB 3.2 Gen 2 (3.1 Gen 2) connectors: 0
Number of SATA III connectors: 4
Front panel audio connector: Yes
ATX Power connector (24-pin): Yes
CPU fan connector: Yes
EPS power connector (8-pin): Yes
Country of origin: China
Supported memory clock speeds: 4800,5200,5600,6000,6200,6400,6800,7000,7200,7600 MHz
Number of memory slots: 4
Memory slots type: DIMM
Unbuffered memory: Yes
Supported memory types: DDR5-SDRAM
ECC сompatibility: Non-ECC
Supported memory clock speed (max): 7600 MHz
Supported memory module capacities: 1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 32GB, 48GB
Maximum internal memory: 192 GB
Memory channels: Dual-channel
Ethernet LAN: Yes
Wi-FI: No
Ethernet interface type: Gigabit Ethernet
Cables included: SATA
Bundled software: Norton® Internet Security (OEM version)rnLAN bandwidth management software
Package height: 54 mm
Package width: 265 mm
Package depth: 265 mm
Package weight: 1.07 kg
Processor manufacturer: AMD
Processor socket: Socket AM5
Supported processor sockets: Socket AM5
Compatible processor series: AMD Ryzen 7000 Series
Maximum internal memory supported by processor: 192 GB
PS/2 ports quantity: 1
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 0
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 0
USB 2.0 ports quantity: 4
HDMI ports quantity: 1
HDMI version: 2.1
DisplayPort version: 1.4
USB connector type: USB Type-A, USB Type-C
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
VGA (D-Sub) ports quantity: 1
DisplayPorts quantity: 1
DVI-D ports quantity: 0
Microphone in: Yes
Headphone outputs: 3
Supported storage drive types: HDD & SSD
RAID support: Yes
Supported storage drive interfaces: M.2, SATA III
Number of storage drives supported: 4
Number of HDDs supported: 1
RAID levels: 0, 1, 10
Depth: 24.4 mm
Height: 35 mm
Width: 244 mm
RAM-Slots: 4
MB-Format: micro-ATX
MB-Socket: AM5
PCI: 0
Serial-or-Paralel: No/No
USB3: 4-8
PCI-Ex1: 1
PCI-Ex16: 1
Onboard-CPU: No
