Sursa Asus TUF Gaming 850W Gold

Compliance certificates: RoHS

On/off switch: Yes

Cooling type: Active

Number of fans: 1 fan(s)

Illumination: No

Fan diameter: 13.5 cm

Product colour: Black

Warranty period: 10 year(s)

Operating temperature (T-T): 0 - 105 °C

Cable tie(s) included: Yes

Cables included: AC, CPU, PCIe, Peripheral (Molex), SATA

Package weight: 3.07 kg

Package depth: 200 mm

Package type: Box

Package width: 310 mm

Package height: 108 mm

Noise level: 0 dB

Mean time between failures (MTBF): 170000 h

ATX version: 3.0

80 PLUS certification: 80 PLUS Gold

Bearing technology: Ball bearing

Power protection features: Over current, Over power, Over voltage, Short circuit, Under voltage

Purpose: PC

Power supply unit (PSU) form factor: ATX

Peripheral (Molex) power connectors (4-pin): 4

CPU power connector (4+4 pin): Yes

Motherboard power connector: 24-pin ATX

Motherboard power cable length: 61 cm

Cabling type: Fully-Modular

PCI Express power cable length: 67.5 cm

PCI Express power connectors (16-pin): 1

Number of SATA power connectors: 5

EPS power connector (8-pin): No

SATA power cable length: 120,400 mm

Peripheral (Molex) power cable length: 150,400 mm

PCI Express power connectors (8-pin): 3

CPU power cable length: 65 cm

Power Factor Correction (PFC) type: Active

Total power: 850 W

Max output current (+12V): 70.8 A

Combined power (+12V): 850 W

Efficiency: 92%

Max output current (+5Vsb): 3 A

Combined power (+5Vsb): 15 W

Max output current (+3.3V): 25 A

Max output current (+5V): 25 A

Max output current (-12V): 0.8 A

Combined power (-12V): 9.6 W

Combined power (+3.3V): 130 W

Combined power (+5V): 130 W

Number of +12V rail(s):

AC input voltage: 100 - 240 V

Weight: 2.38 kg

Height: 86 mm

Width: 150 mm

Depth: 150 mm

Garantia Produsului: 120 luni
