MB Asus PRIME B850-PLUS WIFI

BIOS type: UEFI AMI

BIOS memory size: 256 Mbit

Product colour: Multicolour

Number of M.2 (M) slots: 3

PCI Express x16 (Gen 3.x) slots: 2

PCI Express x16 (Gen 4.x) slots: 1

Audio output channels: 7.1 channels

Windows operating systems supported: Windows 10 x64, Windows 11

Component for: PC

Motherboard chipset: AMD B850

Compatible operating systems: Windows® 11, Windows® 10 64-bit

Motherboard chipset family: AMD

Motherboard form factor: ATX

Parallel processing technology support: Not supported

Number of chassis fan connectors: 4

TPM connector: Yes

Number of CPU fan connectors: 1

12V power connector: Yes

USB 2.0 connectors: 3

S/PDIF out connector: Yes

Number of COM connectors: 1

USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2

Thunderbolt headers: 1

Chassis intrusion connector: Yes

USB 3.2 Gen 2 (3.1 Gen 2) connectors:

Number of SATA III connectors: 4

Front panel audio connector: Yes

ATX Power connector (24-pin): Yes

CPU fan connector: Yes

EPS power connector (8-pin): Yes

Number of memory slots: 4

Memory slots type: DIMM

Unbuffered memory: Yes

Memory channels: Dual-channel

Supported memory types: DDR5-SDRAM

Maximum internal memory: 256 GB

ECC сompatibility: ECC & Non-ECC

Supported memory clock speed (max): 8000 MHz

Ethernet interface type: 2.5 Gigabit Ethernet

Top Wi-Fi standard: Wi-Fi 6E (802.11ax)

Ethernet LAN: Yes

Wi-FI: Yes

Bluetooth version: 5.3

Weight: 1.05 kg

Package height: 273 mm

Package width: 353 mm

Package weight: 1.26 kg

Package depth: 68 mm

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2

HDMI ports quantity: 1

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1

USB 2.0 ports quantity: 2

DisplayPorts quantity: 1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3

DVI-D ports quantity:

Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series

Processor socket: Socket AM5

Processor manufacturer: AMD

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity:

VGA (D-Sub) ports quantity: 0

Microphone in: Yes

Number of HDDs supported: 4

Number of storage drives supported: 7

RAID levels: 0, 1, 5, 10

Supported storage drive types: HDD & SSD

Supported storage drive interfaces: M.2, SATA III

RAID support: Yes

Height: 48 mm

Width: 30.5 mm

Depth: 24.4 mm

USB3: 4-8

Onboard-CPU: No

PCI: 0

MB-Format: ATX

PCI-Ex1: 0

RAM-Slots: 4

MB-Socket: AM5

PCI-Ex16: 5
