DL ECS1250 U7-265 16 1 W11P

PAIA version: GaBi version 1, 2024

Total carbon footprint (kg of CO2e): 148

Carbon emissions, manufacturing (kg of CO2e): 73.26

Carbon emissions, logistics (kg of CO2e): 9.176

Carbon emissions, energy usage (kg of CO2e): 62.752

Carbon emissions, end-of-life (kg of CO2e): 2.96

Processor model: 265

Processor family: Intel Core Ultra 7

Operating system installed: Windows 11 Pro

Bluetooth: Yes

Chassis type: Slim PC

Product colour: Black

Product type: PC

Cable lock slot: Yes

Cable lock slot type: Kensington

Display included: No

Power Supply: 180 W

Audio Chip: Realtek ALC3204

Weight: 4.75 kg

Memory slots: 2x DIMM

On-board graphics card family: Intel Graphics

On-board graphics card: Yes

Discrete graphics card: No

Discrete graphics card model: Not available

On-board graphics card model: Intel Graphics

On-board GPU manufacturer: Intel

Maximum internal memory: 64 GB

Internal memory type: DDR5-SDRAM

Total storage capacity: 1 TB

Memory channels: Single-channel

Memory data transfer rate: 5600 MT/s

Memory layout (slots x size): 1 x 16 GB

Wi-Fi standards: 802.11a, Wi-Fi 5 (802.11ac), 802.11b, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 4 (802.11n)

MU-MIMO: Yes

WLAN controller model: MediaTek MT7920

WLAN controller manufacturer: MediaTek

Cabling technology: 10/100/1000Base-T(X)

Top Wi-Fi standard: Wi-Fi 6 (802.11ax)

Wi-FI: Yes

Antenna type: 2x2

Ethernet LAN: Yes

Ethernet LAN data rates: 10,100,1000 Mbit/s

Neural processor unit (NPU): Intel AI Boost

Sparsity support: Yes

Windows Studio effects support: Yes

AI software frameworks supported by NPU: DirectML, OpenVINO, Windows ML, ONNX RT, WebNN

NPU performance up to: 13 TOPs

GPU performance up to: 8 TOPs

Total processor performance up to: 33 TOPs

Storage temperature (T-T): -40 - 65 °C

Operating temperature (T-T): 10 - 35 °C

Operating relative humidity (H-H): 20 - 80%

Operating shock: 40 G

Storage relative humidity (H-H): 5 - 95%

Operating vibration: 0.26 G

Non-operating vibration: 1.37 G

Non-operating shock: 105 G

Operating altitude: -15.2 - 3048 m

Non-operating altitude: -15.2 - 10668 m

Trusted Platform Module (TPM): Yes

Trusted Platform Module (TPM) version: 2.0

Motherboard chipset: Intel SoC

Audio system: High Definition Audio

Ethernet LAN (RJ-45) ports: 1

Thunderbolt 3 ports quantity:

DisplayPorts quantity: 1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1

USB 2.0 ports quantity: 4

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity:

Combo headphone/mic port: Yes

DisplayPort version: 1.4

HDMI ports quantity: 1

HDMI version: 2.1

Power supply input voltage: 90 - 264 V

80 PLUS certification: 80 PLUS Bronze

Power supply input frequency: 47/63 Hz

Processor threads: 20

Number of processors installed: 1

Processor base power: 65 W

Efficient-core base frequency: 1.8 GHz

Performance-core Max Turbo Frequency: 5.2 GHz

Processor cache: 30 MB

Performance cores: 8

Processor cores: 20

Efficient cores: 12

Processor boost frequency: 5.3 GHz

Processor manufacturer: Intel

Processor cache type: Smart Cache

Performance-core base frequency: 2.4 GHz

Processor generation: Intel Core Ultra (Series 2)

Efficient-core Max Turbo Frequency: 4.6 GHz

Maximum turbo power: 182 W

Trial software: McAfee LiveSafe 1Yr,Microsoft Office Trial

Operating system architecture: 64-bit

Storage media: SSD

Optical drive type: No

Number of SSDs installed: 1

SSD interface: PCI Express 4.0

SSD form factor: M.2

NVMe: Yes

SSD capacity: 1 TB

Total SSDs capacity: 1 TB

Number of storage drives installed: 1

Height: 303.5 mm

Depth: 293 mm

Width: 95 mm
