SURSA GB P550b 550W ATX

Number of fans: 1 fan(s)

Fan diameter: 12 cm

Fan location: Top

On/off switch: Yes

Harmonized System (HS) code: 84733020

Bearing technology: HDB

ATX version: 2.31

Power supply unit (PSU) form factor: ATX

80 PLUS certification: 80 PLUS Bronze

Purpose: PC

Mean time between failures (MTBF): 100000 h

Peripheral (Molex) power connectors (4-pin): 3

Number of SATA power connectors: 6

Motherboard power connector: 20+4 pin ATX

Motherboard power cable length: 55 cm

CPU power connector (4+4 pin): Yes

CPU power cable length: 60 cm

ATX power connector (20+4 pin): Yes

PCI Express connector: Yes

Cabling type: Non-Modular

Peripheral (Molex) power cable length: 500 mm

SATA power cable length: 500 mm

PCI Express power cable length: 55 cm

Floppy drive power connector: 1

Floppy disk drive connector: Yes

PCI Express power connectors (6+2 pin): 2

Max output current (+5Vsb): 3 A

Max output current (-12V): 0.3 A

Power Factor Correction (PFC) type: Active

Input current: 8 - 4 A

Power factor: 0.9

Combined power (+3.3V): 108 W

Combined power (+12V): 522 W

Combined power (+5V): 108 W

Max output current (+3.3V): 18 A

Max output current (+12V): 43.5 A

Hold time: 16 ms

Total power: 550 W

Power protection features: Over current, Over power, Over voltage, Overheating, Short circuit, Under voltage

Combined power (+5Vsb): 15 W

Combined power (-12V): 3.6 W

Max output current (+5V): 15 A

AC input voltage: 100 - 240 V

AC input frequency: 50 - 60 Hz

Depth: 140 mm

Width: 150 mm

Height: 86 mm

Garantia Produsului: 36 luni
