MB MSI B840 GAMING PLUS WIFI AM5

BIOS type: UEFI AMI

ACPI version: 6.5

PCI Express x16 (Gen 3.x) slots: 4

1st M.2 largest key size: 2280

1st M.2 highest PCI Express generation: 4.0

2nd M.2 largest key size: 22110

2nd M.2 highest PCI Express generation: 4.0

Number of M.2 (M) slots: 2

PCI Express x16 (Gen 4.x) slots: 1

Audio output channels: 7.1 channels

Audio Chip: Realtek ALC897

Component for: PC

Motherboard form factor: ATX

Windows operating systems supported: Windows 11 x64

PC health monitoring: CPU, Fan, Temperature, Voltage

Motherboard chipset: AMD B840

Motherboard chipset family: AMD

USB 2.0 connectors: 4

Number of RGB LED pin headers: 3

Number of water pump connectors: 1

Number of CPU fan connectors: 1

USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2

Number of chassis fan connectors: 5

Total number of SATA connectors: 4

Number of SATA III connectors: 4

USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1

RGB LED pin header: Yes

ECC сompatibility: Non-ECC

Supported memory clock speed (max): 8000 MHz

Supported memory clock speeds: 4800,5600,8000 MHz

Memory channels: Dual-channel

Number of memory slots: 4

Memory slots type: DIMM

Supported memory types: DDR5-SDRAM

Maximum internal memory: 256 GB

Ethernet LAN: Yes

Wi-FI: Yes

Top Wi-Fi standard: Wi-Fi 7 (802.11be)

Bluetooth version: 5.4

Ethernet interface type: 2.5 Gigabit Ethernet

DVI-D ports quantity:

USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1

HDMI version: 2.1

USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1

HDMI ports quantity: 1

USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2

USB 2.0 ports quantity: 4

Processor manufacturer: AMD

Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series

Processor socket: Socket AM5

Supported processor sockets: Socket AM5

Maximum internal memory supported by processor: 256 GB

USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity:

VGA (D-Sub) ports quantity: 0

RAID support: Yes

Number of HDDs supported: 4

Supported storage drive types: HDD & SSD

Supported storage drive interfaces: M.2, Micro SATA III

RAID levels: 0, 1, 10

Number of storage drives supported: 6

Width: 243.8 mm

Depth: 304.8 mm

Onboard-CPU: No

PCI: 0

Garantia Produsului: 36 luni
